Orca3D Analysis

Buy Orca3d Analysis

Includes the Speed/Power feature, the CFD interface, and the Weight & Cost feature. This is equivalent to the previous Level 2, except that it does not include the Level 1 functionality and is priced accordingly. The previous Level 2 is equivalent to the Design and Analysis modules together. The ANALYSIS module is not dependent on the DESIGN module so it may be purchased without the DESIGN module.

Highlights of Orca3D Version 3

Unlimited number of conditions (Fixed Load Cases) may be saved for Basic Hydrostatics (replacing the single Design condition).



Floodable Length calculation.



Multiple sets of Section definitions, to be used for hull design and fairing, hydrostatics, or lines drawings and offset tables.



Grasshopper components for Hull Assistants, Basic Hydrostatics & Stability, Planing Hull Resistance, and Displacement Hull Resistance.



Weight Reports may now be grouped by Material.



Stock Material Library now has Export and Merge functions, and the user may specify the location of the Library xml file.



Added flexibility in selection of surface(s) for Planing and Displacement Resistance prediction, as well as the Load Case to be used.



Addition of van Oortmerssen resistance method.



Improved analysis reporting throughout.
